Product Images
Series Overview
F series is the widest 300W small chassis lineup, covering 27 models from 15V/2A up to 300V/1A with output power from 30W to 400W.
Product Highlights
- Voltage0~15V / 0~30V
- Current0~2A / 0~5A / 0~20A / 0~10A
- Power30W / 75W / 300W / 150W
- Form FactorBenchtop / Mini
300W 4-digits 0 TO 30V Ordinary Switch Power Pupply F Series
Series / category: Benchtop DC Power Supply
Product Overview
F series is the widest 300W small chassis lineup, covering 27 models from 15V/2A up to 300V/1A with output power from 30W to 400W. It uses coarse/fine rotary adjustment with C.V./C.C. indicators, a 280×130×165mm chassis, and optional 110V/220V input switching and RS485/RS232/USB communication.
Key Features
- Voltage and current can be preconfigured
- Power display
- Cost-effective
- ON-OFF switch
- Support five powerful protection functions
Available for Global Distribution & OEM
Brand: eTOMMENS
Manufacturer: eTOMMENS
OEM / Private Label: Available
Technical Support: Available
Click a thumbnail to view a larger image.
Model
5 models in this series. Full electrical data is in the specification table below.
- eTM-152F
- eTM-155F
- eTM-1520F
- eTM-305F
- eTM-3010F
Specifications
Swipe horizontally to view the full table.
| Model | Voltage | Current | Power |
|---|---|---|---|
| eTM-152F | 0~15V | 0~2A | 30W |
| eTM-155F | 0~15V | 0~5A | 75W |
| eTM-1520F | 0~15V | 0~20A | 300W |
| eTM-305F | 0~30V | 0~5A | 150W |
| eTM-3010F | 0~30V | 0~10A | 300W |
Applications
- Circuit board detection
- Mobile phone detection
Communication Interface
- Optional 220/110 switching interface
Protection Functions
- Support five powerful protection functions
Quick Answers
What is the 300W 4-digits 0 TO 30V Ordinary Switch Power Pupply F Series?
The 300W 4-digits 0 TO 30V Ordinary Switch Power Pupply F Series is a DC power supply from eTOMMENS. 5 models are listed in the specification table on this page.
Which control interfaces does it support?
Optional 220/110 switching interface
How do I get a quotation for this model?
Send your requirements to wendy@etommensglobal.com and our engineers will recommend a suitable model and quote.
OEM & Private Label
OEM and private-label service is available for this series. Brand: eTOMMENS. Manufacturer: eTOMMENS. Technical support: available. Contact sales to discuss your OEM requirements.
